Roundfin RD-3 3-Body Mortuary Refrigerator
1. SECOP compressor for reliable, energy-efficient cooling
2. Three independent compartments with separate temperature control per compartment
3. Full 304 stainless steel construction with fully welded and polished seams
4. High-density blowing agent filling for superior insulation
5. Built-in alarm system with temperature deviation alert
6. Heavy-duty casters with brake for mobility and stable positioning
Product Overview
The Roundfin RD-3 is a 3-room front-opening mortuary refrigerator designed for hospital morgues, funeral homes, and forensic facilities. Each compartment operates independently with dedicated temperature control, providing flexible storage conditions for different preservation requirements. Built from full 304-grade stainless steel with fully welded and polished seams, the RD-3 combines durability with reliable, energy-efficient cooling powered by a SECOP compressor.
Key Specifications at a Glance
Capacity: 3-Body | Material: 304 Stainless Steel | Compressor: SECOP | Temperature: 0 to -10°C
Custom Design Solutions Available
We provide tailored design proposals and accept full customization — dimensions, materials, temperature ranges, configurations, and facility-specific integrations. Contact our engineering team to discuss your project requirements.
Technical Specifications
| Model | RD-3 |
| Configuration | 3 compartments, front-opening doors |
| Material | Stainless Steel 304 (optional: 316) |
| External Size | 2280 × 800 × 1785 mm |
| Outer Packing Size | 2320 × 850 × 1900 mm |
| Volume | 4.6 m³ |
| Rate of Work | 840 W / 1.2 A |
| Thickness | Outer: 1.0 mm | Body tray: 1.0 mm | Inner: 0.6 mm |
| Body Tray Size | 1940 × 580 mm |
| Compartment Inner Size | 1950 × 630 × 440 mm |
| Compressor | SECOP |
| Compressor Position | Rear-mounted |
| Refrigerant | SECOP compressor: R404A / R452A | Chinese compressor: R134A |
| Temperature Range | Standard: 0 to -10°C (±1°C) | Adjustable: 5°C to -15°C |
| Temperature Control | Independent per room |
| Insulation | High-density blowing agent filling |
| Alarm System | Temperature deviation alert |
| Voltage | 220 V / 50 Hz (110 V / 60 Hz) |
| Mobility | Heavy-duty casters with brake |
| Welding | Fully welded and polished |
Key Features
SECOP Compressor — One of the most trusted compressor brands in commercial refrigeration. Delivers consistent, energy-efficient cooling with a long service life.
Independent Compartment Control — Each of the three compartments has dedicated temperature control, allowing different preservation conditions for different cases simultaneously.
Full Stainless Steel Construction — 304-grade stainless steel body and trays with fully welded and polished seams. Resists corrosion from mortuary cleaning agents and ensures long-term hygiene.
High-Density Insulation — Blowing agent filling provides superior thermal retention, reducing compressor runtime and energy consumption.
Built-in Alarm System — Temperature deviation alert immediately notifies staff of any cooling irregularities, protecting body preservation integrity.
Mobility with Stability — Heavy-duty casters with brake allow repositioning for cleaning or layout changes, then lock securely in place.
OEM and Custom Accepted — Dimension modifications, material upgrades, temperature range adjustments, and additional features available on request.
Product Video
FAQ
How many bodies can the RD-3 store?
The RD-3 has three independent compartments, each accommodating one body tray. It is designed for facilities needing compact multi-body storage with separate temperature zones.
What is the difference between SECOP and Chinese compressor options?
The SECOP compressor uses R404A or R452A refrigerant and is preferred for its proven reliability and global service network. The Chinese compressor uses R134A refrigerant and offers a more cost-effective option. Both deliver the same temperature range.
Can the temperature be adjusted?
Yes. Each room can be independently set between 5°C and -15°C. The standard factory setting is 0 to -10°C (±1°C).
Does the RD-3 require professional installation?
The RD-3 is delivered pre-assembled and requires only a standard power connection. It is shipped on casters for easy positioning. Roundfin provides an installation manual and remote technical support.
